ISO900/IATF16949 Rare Earth Permanent Disc/Block/Arc/Ring/Trapezoid NdFeB Neodymium Magnets
Neodymium magnets, alongside samarium magnets, are part of the rare earth group and represent the latest generation of magnetic materials. These magnets possess properties significantly superior to traditional options, currently standing as the most powerful magnets on the market.
With greater remanence and high coercivity, neodymium magnets are widely utilized across industrial sectors. Even when smaller in size compared to ferrite magnets, they can withstand more strength and provide superior magnetic performance.
| Product Name | Material | Code / Grade | Shapes | Delivery |
|---|---|---|---|---|
| Neodymium Magnets | NdFeB | N30-N52, N30M-N52M, N30H-N52H, SH, UH, EH, AH series | Disk, Block, Ring, Cylinder, Trapezoid, etc. | 15-30 days |
| Type | Grade | Br (T) | HCB (kA/m) | HCJ (kA/m) | (BH)max (kJ/m3) | Tw Max (ºC) |
|---|---|---|---|---|---|---|
| N | N35-N54 | 1.18 - 1.45 | 836 - 860 | 876 - 955 | 263 - 438 | 80 |
| M | 35M-52M | 1.18 - 1.42 | 860 - 1035 | 1035 - 1114 | 263 - 422 | 100 |
| H | 33H-50H | 1.14 - 1.39 | 844 - 1035 | 1274 - 1353 | 247 - 406 | 120 |
| SH | 33SH-48SH | 1.14 - 1.37 | 844 - 1019 | 1512 - 1592 | 247 - 390 | 150 |
