Basic Specifications
Roof Shape
Venlo/Curved/Peak
Control System
IoT Intelligent Climate Computer
Irrigation
Automated Fertigation
Technical Parameters
| Component |
Material & Specifications |
| Skeleton | Hot dip galvanized Q195-235 Steel (20+ years service life) |
| Roof Cover | 150 micron PO film (Optional PC Panel) |
| Internal Shading | Motor-driven rack and pinion system |
| Control System | Temp/Humidity/Light/CO2 Sensors integrated |
| Door | 2m * 2m Aluminum alloy sliding door |
Standard Commercial Dimensions
| Greenhouse Span |
6-10m, customized |
| Greenhouse Bay |
2m, 2.5m, 4m, 5m, customized |
| Greenhouse Height |
3-7m, customized |
Visual Presentation
Unmatched Advantages
-
Thermal Insulation & Energy Saving: Multi-wall panels provide air pockets for exceptional insulation, reducing seasonal heating and cooling costs.
-
High Impact Resistance: PC sheets are up to 200 times stronger than glass, protecting crops from hail and debris while providing diffused light for uniform photosynthesis.
-
Long-term Durability: The frame uses hot-dip galvanized steel for superior anti-corrosion, ensuring a service life exceeding 20 years.
-
Smart Farming Optimized: Seamless integration with IoT climate computers, automated fertigation, and shading systems.
Product Overview
Our flaghsip Commercial Multi-Span Polycarbonate (PC) Greenhouse is engineered for professional growers. It delivers maximum yield and cost-effectiveness for tomatoes, lettuce, cucumbers, and ornamental plants. It is ideal for large-scale production, U-Pick agritourism farms, and specialized nurseries.
Frequently Asked Questions
Q1: Can the greenhouse size be customized for my land?
Yes, the spans (8m-12m), bay widths, and gutter heights (4m-8m) are fully customizable to meet specific site requirements.
Q2: How long is the service life of the structure?
The framework is made of hot-dip galvanized steel, providing superior anti-corrosion protection for over 20 years.
Q3: What crops are suitable for this greenhouse?
It is ideal for high-yield tomatoes, lettuce, cucumbers, strawberries, and various nursery seedlings or ornamental plants.
Q4: Does it support automated climate control?
Yes, our systems are "Smart-Ready," designed to integrate with IoT Intelligent Climate Computers and automated sensor arrays.
Q5: How does it handle extreme weather conditions?
The multi-span design is rated for wind loads of 0.55 kN/M² and snow loads of 0.35 kN/M², using high-impact resistant polycarbonate for protection against hail.
Q6: What are the packaging standards for international shipping?
All components are packed according to professional export standards to ensure safety during long-distance maritime transport.
